| 檢測氣體 | NH3/H2/CO/H2S/CH4/NO2/SO2/O3/PH3/O2任選一種 | ||
| 重復性 |
NH3/H2/CO(1000ppm)/H2S/CH4/NO2/SO2/O3/PH3:≤2% CO(2000ppm) :≤3% O2:≤1% |
||
| 穩(wěn)定性 | CO(1000ppm)/H2S/H2/NO2/SO2/NH3/PH3 | ≤2%信號值/月 | |
| CH4/O3 | ≤7%信號值/年 | ||
| CO(2000ppm)/O2 | ≤5%信號值/年 | ||
| 絕緣電阻 | ≥20MΩ | ||
| 報警功能 | 聲、光、震動 | ||
| 工作溫度 | -10℃-50℃ | ||
| 工作濕度 |
NH3/H2/CO/H2S/NO2/SO2/O3/PH3：15~90%RH 無冷凝 O2：5~95%RH 無冷凝 CH4：0~95%RH 無冷凝 |
||
| 工作電壓 | DC3.7V (鋰電池容量3000mAh)，Micro-B口供電為5VDC | ||
| 工作壓力 | NH3/H2/CO(1000ppm)/H2S/SO2/O2/O3/PH3 | 90~110kPa | |
| NO2 | 91~111kPa | ||
| CH4 | 80~116kPa | ||
| CO(2000ppm) | 80~120kPa | ||
| 充電時間： | 6h - 8h | ||
| 待機時間： | 不少于8h連續(xù) | ||
| RS- | 公司代號 | ||||
| MG41- | 手持式氣體檢測儀外殼 | ||||
| O2- | 30VOL | O2變送器30%VOL量程 | |||
| H2S- | 100P | H2S變送器100 ppm量程 | |||
| CH4- | 100LEL | CH4變送器100%LEL量程 | |||
| CO- | 1000P | CO變送器1000 ppm量程 | |||
| 2000P | CO變送器2000ppm量程 | ||||
| NO2- | 20P | NO2變送器20ppm量程 | |||
| 2000P | NO2變送器2000ppm量程 | ||||
| SO2- | 20P | SO2變送器20ppm量程 | |||
| 2000P | SO2變送器2000ppm量程 | ||||
| H2- | 1000P | H2變送器1000ppm量程 | |||
| NH3- | 50P | NH3變送器50ppm量程 | |||
| 100P | NH3變送器100ppm量程 | ||||
| PH3- | 20P | PH3變送器20ppm量程 | |||
| O3- | 100P | O3變送器100ppm量程 | |||
